FRP Filter Tank atau Tabung Filter Air FRP digunakan untuk menempatkan media filter pada aplikasi pengolahan air. Water Filter Vessel ini terbuat dari bahan fiberglass yang diperkuat dengan polyethylene, umumnya digunakan untuk proses filterisasi, water softener atau deminerlisasi. Tabung Filter Air Fiberglass memiliki kekuatan dan daya tahan tinggi karena pada permukaannya dibentuk dari bahan polyethylene yang memiliki tingkat kerapatan yang tinggi. PT Citra Tirtamas menjual Tabung Filter Air FRP dengan harga sangat kompetitif mulai dari ukuran diameter 10 inch sampai dengan ukuran diameter 48 inch, yang sudah dilengkapi dengan Top Bottom Strainer dan Manual Valve, tersedia merk Pentair dan Nanotech.
Specification FRP Filter Tank :
A. Material
- Inner shell : Polyethylene (PE) seamless one-piece tank liner
- Outer shell : Continuous strands of fiber-glass with high strength epoxy resin
- Bottom base : FRP round base
- Opening : 2.5” and 4"
B. Parameter
- Working Pressure : ≤1.0MPa(150PSI)
- Working Temperature : ≤49°C
- Media : silica sand/activated carbon/resin
C. Application
All feed water & waste water treatment application, included multi-media filter & softener
D. Type :
1. Diameter 10 inch Type 1054
- Size : Diameter 255mm x Height 1390mm
- Volume Tank : 62 liter
- Opening : 2,5" inch
- Base : Standard
- Flowrate : 0,6 - 1,5 m3/hr
- Volume Filter Media : 35 kg
- Weight : 9,5 kg
2. Diameter 13 inch Type 1354
- Size : Diameter 330mm x Height 1400mm
- Volume Tank : 104 liter
- Opening : 2,5" inch
- Base : Standard
- Flowrate : 2,0 - 2,5 m3/hr
- Volume Filter Media : 60 kg
- Weight : 13,5 kg
3. Diameter 14 inch Type 1465
- Size : Diameter 355mm x Height 1670mm
- Volume Tank : 146 liter
- Opening : 2,5" inch
- Base : Standard
- Flowrate : 2,5 - 3,0 m3/hr
- Volume Filter Media : 82 kg
- Weight : 16 kg
4. Diameter 16 inch Type 1665
- Size : Diameter 400mm x Height 1670mm
- Volume Tank : 188 liter
- Opening : 2,5" inch
- Base : Standard
- Flowrate : 3,2 - 4,5 m3/hr
- Volume Filter Media : 106 kg
- Weight : 19 kg
5. Diameter 18 inch Type 1865
- Size : Diameter 450mm x Height 1670mm
- Volume Tank : 237 liter
- Opening : 4" inch
- Base : Tripod
- Flowrate : 4,5 - 5,0 m3/hr
- Volume Filter Media : 133 kg
- Weight : 25 kg
6. Diameter 24 inch Type 2472
- Size : Diameter 600mm x Height 1850mm
- Volume Tank : 441 liter
- Top Bottom Opening : 4" inch
- Base : Tripod
- Flowrate : 6,2 - 8,2 m3/hr
- Volume Filter Media : 247 kg
- Weight : 47 kg
7. Diameter 30 inch Type 3072
- Size : Diameter 750mm x Height 1850mm
- Volume Tank : 676 liter
- Top Bottom Opening : 4" inch
- Base : Tripod
- Flowrate : 8,2 - 12,2 m3/hr
- Volume Filter Media : 380 kg
- Weight : 64 kg
8. Diameter 36 inch Type 3672
- Size : Diameter 900mm x Height 1850mm
- Volume Tank : 857 liter
- Top Bottom Opening : 4" inch
- Base : Tripod
- Flowrate : 13,2 - 16,2 m3/hr
- Volume Filter Media : 480 kg
- Weight : 80,5 kg
9. Diameter 48 inch Type 4872
- Size : Diameter 1200mm x Height 1850mm
- Volume Tank : 1202 liter
- Top Bottom Opening : 6" inch
- Base : Tripod
- Flowrate : 22 - 27 m3/hr
- Volume Filter Media : 842 kg
- Weight : 166 kg
